The liquid crystal display module and the liquid crystal module refer to components for assembling a liquid crystal display device, a connecting member, a peripheral circuit for controlling and driving, a PCB circuit board, a backlight, and a structural member.
The technical specifications of the liquid crystal display module (LCM) currently available from Xin Hongtai are as follows:
The number of dot matrix is: 122*32, 128*64, 160*32, 256*32, 192*64, 240*64, 160*128, 240*128, 256*128, 320*240, 640*200, etc. Product
Working temperature: normal temperature 0 ~ +50 ° C, wide temperature -20 ~ +70 ° C, ultra wide temperature -30 ~ + 80 ° C;
Interface type: 3-wire or 4-wire SPI serial port, 8-bit or 16-bit MCU parallel port, I2C, RS232 or RS485, USB interface;
Display mode: black on white, black on yellow and green, black on blue, white on blue, white on black, custom silk screen, etc.
| Checklist | Model | Product type | Show contents | Product map |
Outline size (mm) |
Horizon (mm) |
Display size mm/inch |
Point spacing mm |
Visual angle | Brightness | Pin | Interface | Instructions | Working temperature | Voltage | Driver chip model |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4.36 inch 192x64 Graphic Display Module | STN Positive Display | Gray Background Blue Text | Arduino | MCU | AIP31108 HTM19264B-11W-N5P | Graphic LCD Module | 192x64 |
|
120.2x62.0x10.0 | 103.92x38.94 | 97.846x32.462 | 0.508x0.508 | 6H | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | AIP31108 | |||
| 4.36 inch 192x64 Graphic Dot Matrix Display Module | DFSTN Negative Display | Arduino | MCU | AIP31108 HTM19264B-41W-N5P | Graphic LCD Module | 192x64 |
|
120.2x62.0x10.0 | 103.92x38.94 | 97.846x32.462 | 0.508x0.508 | 6H | 21PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | AIP31108 | ||
| 4.36 inch 192x64 Graphic Dot Matrix Display Module/STN Negative Display/Arduino/MCU/AIP31108 HTM19264B-25W-N5P | Graphic LCD Module | 192x64 |
|
120.2x62.0x10.0 | 103.92x38.94 | 97.846x32.462 | 0.508x0.508 | 6H | 21PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | AIP31108 | ||
| 4.36" 192x64 Graphic Dot Matrix Display Module | FSTN+ | Gray Text on White Background | Arduino | MCU | AIP31108 HTM19264B-31W-N5P | Graphic LCD Module | 192x64 |
|
120.2x62.0x10.0 | 103.92x38.94 | 97.846x32.462 | 0.508x0.508 | 6H | 21PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | AIP31108 | ||
| 4.36 inch 192x64 graphic dot matrix display module/FSTN+RGB red, green and blue backlight/Fully transparent polarizer HTM19264A-35S-A5P | Graphic LCD Module | 192x64 |
|
130.0x65.0x13.5 | 103.92x38.94 | 97.486x32.462 | 0.508x0.508 | 6H | 20PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | AIP31108 | ||
| 4.36 inch 192x64 Graphic Dot Matrix Display Module | STN+ | 5.0v | Yellow-green Backlight | MCU | AIP31108 HTM19264A-11Y-A5P | Graphic LCD Module | 192x64 |
|
130.0x65.0x13.5 | 103.92x38.94 | 97.486x32.462 | 0.508x0.508 | 6H | 20PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | AIP31108 | ||
| 4.36 inch 192x64 Graphic Dot Matrix Display Module | STN+ | 5.0v | Gray Background Blue Text | MCU | AIP31108 HTM19264A-11W-A5P | Graphic LCD Module | 192x64 |
|
130.0x65.0x13.5 | 103.92x38.94 | 97.486x32.462 | 0.508x0.508 | 6H | 20PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | AIP31108 | ||
| 4.36 inch 192x64 Graphic Dot Matrix Display Module | DFSTN- | 5.0v | Black Background White Text | MCU | AIP31108 HTM19264A-41W-A5P | Graphic LCD Module | 192x64 |
|
130.0x65.0x13.5 | 103.92x38.94 | 97.486x32.462 | 0.508x0.508 | 6H | 20PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | AIP31108 | ||
| 4.36 inch 192x64 Graphic Dot Matrix Display Module | FSTN+ | 5.0v | MCU | AIP31108 | Arduino HTM19264A-31W-A5P | Graphic LCD Module | 192x64 |
|
130.0x65.0x13.5 | 103.92x38.94 | 97.486x32.462 | 0.508x0.508 | 6H | 20PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | AIP31108 | ||
| 4.36 inch 192x64 Graphic Dot Matrix Display Module | FSTN+ | 5.0v | MCU | AIP31108 | Arduino HTM19264A-31W-A5P | Graphic LCD Module | 192x64 |
|
130.0x65.0x13.5 | 103.92x38.94 | 97.486x32.462 | 0.508x0.508 | 6H | 20PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | AIP31108 |
