Since the ordinary TFT display screen is basically the FPC soft cable lead-out, it is connected to the customer's main board through soldering or socket, and some products also need to have peripheral component circuits to be used.
In order to facilitate the use of customers, Xin Hongtai HOTLCD has designed a TFT module with a fixed adapter plate structure. It is a TFT module that is transferred from the ordinary TFT display to the customer's motherboard by adding PCB. The advantage is that the structure is convenient and convenient. Soldering peripheral components and interface options can be connected to the customer's motherboard.
At present, there are 1.44 inch, 1.8 inch, 2.0 inch, 2.4 inch, 2.8 inch, 3.2 inch, 3.5 inch and other sizes for customers to choose, generally used in industrial equipment.
| Checklist | Model | Product type | Show contents | Product map |
Outline size (mm) |
Horizon (mm) |
Display size mm/inch |
Effective size mm |
Visual angle | Brightness | Pin | Interface | Instructions | Working temperature | Voltage | Driver chip model |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 7.0inch TFT LCD Display Module/1024x600 resolution/wide temperature/IPS full viewing angle/sunlight viewable/optional capacitive touch/HTM-H070A2-RGB-B06 | TFT Module | 1024x600 |
|
186.90x108x8.3 | 7.0 | 7.0 | 154.21x85.92 | Full view | 700cd/m2 | FPC-40PIN | RGB | With capacitive touch function | -30~70℃ | 5.5V | T.B.D | |
| 1.3 Inch Color TFT Square LCD Module Display 240x240 Pixels SPI Suitable For Arduino, Handheld Devices HTM-H013A2-SPI-A01 | TFT Module | 240x240 |
|
30x36x2.13 | 1.3" | 1.3" | 23.4x23.4 | Full view | 300cd/m2 | 8pin | SPI | Anti-static ESD 8KV | -20~70℃ | 3.3V | ST7789 | |
| 2.8 inch color TFT LCD module Display 240x320 pixels SPI for Arduino, handheld devices HTM-TFT028A16-SPI | TFT Module | 240x320 |
|
88x53.3x10.9 | 2.8 | 2.8 | 57.6x43.2 | Full view | 700cd/m2 | 8pin | SPI | Anti-static ESD 8KV | -30~80℃ | 3.3V | ST7789V | |
| 7.84 Inch Bar Style Capacitive Touch IPS TFT LCD Display 1280x400 MCU For Car Monitor HTM-TFT078A01-MCU-CTP | TFT Module | 1280x400 |
|
221.8×71.8×9 | 7.84 | 7.84 | 190.88x60.2 | Full view | 450cd/m2 | 48pin | MCU | Anti-static ESD 8KV | -20~70℃ | 3.3V | RA8889 | |
| 7.84 Inch Bar Style IPS TFT LCD Display 1280x400 MCU For Car Monitor HTM-TFT078A01-MCU | TFT Module | 1280x400 |
|
221.8×71.8×9 | 7.84 | 7.84 | 190.88x60.2 | Full view | 450cd/m2 | 48pin | MCU | Anti-static ESD 8KV | -20~70℃ | 3.3V | RA8889 | |
| 7 Inch Capacitive Touch IPS 1024x600 TFT LCD Module Display Panel With Controller Board HTM-H070A2-RGB-B06 | TFT Module | 1024x600 |
|
186.9x108x8.3 | 7.0 | 7.0 | 156.1x88.5 | Full view | 700cd/m2 | RGB | Anti-static ESD 8KV | -20~70℃ | ||||
| 7 Inch IPS 1024x600 TFT LCD Module Display Panel With Controller Board HTM-H070A2-RGB-B06 | TFT Module | 1024x600 |
|
186.9x108x8.3 | 7.0 | 7.0 | 156.1x88.5 | Full view | 700cd/m2 | RGB | Anti-static ESD 8KV | -20~70℃ | 5.0V | |||
| 3.5 INCH LCD DISPLAY 320X480 SPI TFT MODULE PANEL WITH LCD CONTROLLER BOARD HTM-H035A11-SPI-A05V0 | TFT Module | 320x480 |
|
57x104x5.6 | 3.5 | 3.5 | 48.96x73.44 | 12H | 500cd/m2 | 40pin | SPI | Anti-static ESD 8KV | -20~70℃ | 3.3V | ST7796 | |
| 2.8 Inch 240x320 ST7789 TFT Module Panel With LCD Controller Board LCM-TFT028T2 | TFT Module | 240x320 |
|
51.0x81.2x2.3 | 2.8 | 2.8 | 43.2x57.6 | 6H | 10pin | SPI | Anti-static ESD 8KV | -20~70℃ | 3.3V | ST7789 | ||
| 1.44 Inch 128x128 TFT Module Panel With LCD Controller Board HTM-H014A05-SPI-A01 | TFT Module | 128x128 |
|
30x46.5x11.3 | 1.44 | 1.44 | 25.5x26.5 | Full view | 300cd/m2 | 12pin | SPI | Anti-static ESD 8KV | -20~70℃ | 3.3V | ST7735 |
